SIA – 030
SIA – 030 Signature Series
A balanced Class A integrated amplifier. The latest design from Vitus Audio. The unit utilizes modified components from the Masterpiece series as well as completely new ones, specially designed for the SIA-030. The amplifier can operate in two modes, “Classic” and “Rock,” by changing the configuration of the output stage, which alters the sound character. Volume control is implemented via a resistor ladder with 0.5 dB steps across the entire range. The amplifier is equipped with five line inputs. Two of them are RCA inputs; the rest are XLR inputs. Optional modules are available for the amplifier that you can install yourself. These include a DAC with a streamer and an MM/MC phono preamp. The phono preamp module features two RCA inputs, each with independent controls (gain, load) for each input. This allows you to connect two independent analog systems.
Technical Specifications:
| Parameter | Value |
|---|---|
| Product Type | Balanced Integrated Amplifier |
| Volume | Relay controled fixed resistor network |
| Resolution | -99 to +13 dB = 0,5dB steps |
| Inputs | 3xXLR analog / 2xRCA analog |
| Input Impedance | 10KΩ |
| Input Sensitivity | 2/4/8V RMS |
| Outputs | 1x set balanced speaker out / 1x preout (RCA) |
| Output Power | 2x30w rms ClassA (8Ω) / 2x1200w rms ClassAB (8Ω) – switchable |
| Remote Control | VA RC-010 remote included |
| Power Cable | Not included |
| Dimensions | 268(H) x 435(W) x 530(D)mm |
| Weight | 63Kg |
